At EICMA, the now French-based motorcycle brand introduced the Lawrence Dagger.
For 21 years they actually produced in Nottingham, England, until the factory was seized during WW2 to be used for war purposes. The brand has since been reactivated and production established in France.
Lawrence
Back in March 2021, Brough Superior introduced the Lawrence, a limited edition machine based on the Superior SS 100, limited to 188 units. The motorcycle was dedicated to Thomas Edward Lawrence, better known as Lawrence of Arabia and a British national hero. He fought as a guerrilla fighter in Arabia during World War I.
Lawrence Dagger
Another model dedicated to him has now been unveiled at EICMA. “Dagger” – the weapon Lawrence always carried on his belt.
The original base model, the Superior SS 100 was put on 18 inch wheels. The Lawrence based on it and also a following Lawrence Nefud got a 19 inch wheel in the front and a 17 inch wheel in the rear. On the Dagger, they now went back to 17 inch wheels covered with 120/70 17 inch front and 200/55 17 inch rear tires.
In addition, the Dagger is the first motorcycle in the portfolio to be homologated to Euro5.
Engine and performance
The 997cc V-twin in the Dagger produces 102 hp (75 kW) at 9,600 rpm and 87 Nm at 7,300 rpm. The engine features overhead camshafts, 88-degree cylinder injection, four valves per cylinder and water cooling.
Exhaust gases are discharged via a sidepipe muffler.
Chassis
The engine is transplanted into a lightweight titanium frame. At the front is a so-called Hossack fork, basically an upright-mounted swingarm with double longitudinal link. It, too, is made of fine titanium.
A total weight of 200 kg is specified, which is supposed to be perfectly balanced, i.e. exactly 50% should be applied to both the front wheel axle and the rear wheel.
Equipment
Modern LED technology is used for the lighting, otherwise the electronics are very minimalist. Also noble are the aluminum wheels, which were not cast, the wheels are CNC milled from the solid aluminum block.
The fairing is made of carbon.
The Brough Superior Lawrence Dagger can already be ordered, but no price has been announced yet. If you look at the components, then you can assume that it will not be exactly cheap. However, this also fits the company’s history, as Brough Superior was already considered a Rolls-Royce among motorcycles in the past.
CARACTÉRISTIQUES TECHNIQUES BROUGH SUPERIOR LAWRENCE / DAGGER
|
LONGUEUR |
2240mm |
|
LARGEUR |
920mm |
|
HAUTEUR D’ASSISE |
810mm |
|
EMPATEMENT |
1540mm |
MOTEUR
|
TYPE |
997 cm³, Bicylindre en V à 88°, DOHC, 4 temps, refroidissement liquide, 4 soupapes par cylindre, entraînement de distribution composite par chaîne et engrenage |
|
DIMENSIONS |
94 mm x 71,8 mm |
|
PUISSANCE |
102 CV (75kW) à 9 600 tours/ minute Homologation Euro 5 |
|
COUPLE |
87 Nm (64 lb-ft) à 7 300 tours/ minute |
|
RATION DE COMPRESSION |
11 : 1 |
|
ALIMENTATION |
Injection électronique de carburant avec ECU Synerject et 2 corps papillons Synerject de 50 mm à simple injecteur |
|
RÉSERVOIR |
17 L |
|
BOÎTE DE VITESSES |
6 rapports |
|
EMBRAYAGE |
Multi-disques en bain d’huile avec commande hydraulique, anti-dribble |
CHASSIS
|
CADRE |
Cadre en titane usiné, sous-cadre en aluminium usiné dans la masse CNC |
|
SUSPENSION AVANT |
Type Fior avec fourche en aluminium, double triangle articulé et amortisseur réglable en précharge et détente, débattement 120 mm |
|
SUSPENSION ARRIÈRE |
Bras oscillant en fonderie d’aluminium CNC pivotant dans les carters moteur, amortisseur réglable en précharge et détente, débattement 130mm |
|
ANGLE DE CHASSE |
24,6° avec chasse de 108,3 mm avec déport de 37,1mm |
|
FREIN AVANT |
Double disque Beringer en acier inox 320 mm. Étriers Beringer doubles pistons à fixation radiale |
|
FREIN ARRIÈRE |
Disque Beringer en acier inox 230 mm. Étriers Beringer à deux pistons |
|
ROUES |
Jantes forgées en aluminium CNC (7 bâtons) |
|
PNEU AVANT |
120/70 R17 sur jantes 3,5 pouces |
|
PNEU ARRIÈRE |
200/55 R17 sur jantes 6,25 pouces |
|
POIDS / RÉPARTITION |
200 Kg (410 lb) répartis 50/50 |
